Veksler’s Orifice Plate Assemblies stand as a cornerstone for precise flow measurement in a wide range of industrial applications, including clean liquids, steam, and gases. Designed in accordance with the stringent standards of BS 1042/IS, these plates ensure accuracy levels of 1/2 to 1%. Our offerings encompass both the plate itself and the complete assembly, available with or without matching flanges and a carrier ring.
The core plate is meticulously machined from high-grade materials such as SS 304, SS 316, or Monel, ensuring durability and reliable performance. The accompanying flanges can be selected from a variety of options including ASTM A 105, A 182, SS 304, SS 316, and Monel. These flanges can be tailored to suit the specific demands of your process, with ratings ranging from 150#/300#/600# or more as per your requirements.
Specifications for our Orifice Plate Assemblies encompass a comprehensive array of features, including a choice of material for the orifice plate itself, a diverse line size range from 15NB to 600 NB, and options for various types of flanges, such as weld neck, slip-on, and socket weld. Our commitment to quality extends to every component, including ASTM-A-193 GR – B7 studs/bolts, ASTM-A-193 GR – 2H nuts, and a selection of gasket materials like CAF, Teflon, or Spiral Wound.
| Orifice Plate | SS 316, SS304, Monel |
| Line Size | 15NB to 600 NB |
| Flanges | ATM A 105, A 182, SS 304, SS 316, Monel |
| Optional | IBR Approved Flanges |
| Type of Flanges | Weld neck, Slip-on, Socket weld |
| Studs/Bolts | ASTM-A-193 GR – B7 |
| Nuts | ASTM-A-193 GR – 2H |
| Gasket | CAF/Teflon/Spiral Wound |
Veksler’s reputation as renowned Orifice Plate manufacturers in India is a testament to our dedication to precision and performance. Connect with us today to fulfill your Orifice plate requirements, and experience the reliability and accuracy our products bring to your flow measurement needs.
